• Model NO.: LED Linear Light LL-4932
  • Lamp Body Material: Aluminum
  • Base Type: G8
  • IP Rating: IP40
  • Voltage: 100-277V
  • LED Chips: Epistar
  • Material: Aluminum Extrusion
  • Beam Angle: 110 Degree
  • IP Code: IP40
  • LED Type: 2835 SMD LED
  • Input Voltage: AC 100-277V 50/60Hz
  • Transport Package: 10PCS in Boxes
  • Origin: China
  • Color Temperature: Cool White
  • Style: European
  • Irradiated Area: 10-15㎡
  • Certification: CCC, CE, EMC, LVD, RoHS
  • Beaming Angle: 110
  • Product Name: LED Linear Light Ll-4932
  • Reflector: Milky Cover
  • Saving Energy: 50%
  • Input Power: 30W
  • Standard Warranty: 3 Years
  • Trademark: Vista
  • Specification: L1250*W95*H62mm
  • HS Code: 854420
Cool White 3000*3300K IP40 LED Linear Light for offices

Cool White 3000*3300k IP40 LED Linear Light for Offices


LED linear light is exclusively designed for designer and architect with imagination and personal style. LED linear light adopt premium aluminum profile, different dimension and size, easy to install.
3 types install lotion method: ceiling mounted type, suspended type and embedded type, and different customized dimensions are also acceptable, which can meet installation requirement of different fields and occasions.

Product Technical Parameters:
led linear light LL-4932
Color  coolwhite(5000-6500K),natural white(3700-4500K) warm white(2700-3200K), other available.
Input Voltage AC 100-277V 50/60Hz
LED type 2835 SMD LED
Input Power 30W
Reflector Milky cover
Power factor >0.95
Beam angle 110 Degree
Saving energy 50%
Material Aluminum Extrusion
IP code IP40
Standard warranty 3 years
          Life span more than 50,000Hrs,CE Certified


Application:
- Hotels
- Conference/Meeting rooms
- Factories and offices
- Commercial purposes
- Residential / Institution buildings
- Schools, colleges, universities and hospitals
-Places which needs energy saving and high color rendering index lighting

Cool White 3000*3300k IP40 LED Linear Light for Offices

Ordering information:

Part Number Emitting Color LED
Quantity		 Bean Angle Voltage(V) Power
(W/M)		 Current
(A)/5M		 CRI Lumen
(M)		 PF
ZL-All4932-30WW 3000*3300K 288PCS/M 110° AC100-277V 50/60Hz 30W 1.85A >90 1471LM
>0.95
ZL-All4932-30NW 4000-4500K 288PCS/M 110° 30W 1.85A >90 1471LM
ZL-All4932-30W 5000-6000K 288PCS/M 110° 30W 1.85A >90 1471LM

Electrical Connection:

Cool White 3000*3300k IP40 LED Linear Light for Offices

Packing Specification:
Net weight :1.5Kg
Gross weight/Carton :20.5Kg
Packing size :1270*510*155mm
4.1pcs per inner box ,10 inner boxes per carton .
All dimension units are millimeter

Cool White 3000*3300k IP40 LED Linear Light for Offices



Notice:
1. Please read the specification first, to make sure the service environment matches the condition in the specification before using.
2. Please confirm the applicable power supply before using.
3. Make sure the switch of product is off before connect to the power supply to prevent electric shock.
4. Operation against rules may damage your property even harm to your personal safety.
5. Preliminarily estimate required quantity of LED linear lights, then according to the power  rating of single linear light to figure out the total power and design power supply plan
6. Dangerous high voltage, Non-professionals are not allowed to maintain the products
7. If the exterior flexible cable or wire is damaged, it must exchange by the supplier, its
agent or other similar qualified personnels to avoid dangers.

Our Company

Cool White 3000*3300k IP40 LED Linear Light for Offices

We are a professional manufacturer of various kinds of LED lighting products in Shenzhen China. Our current products lines range include: LED Flexible Strip light, LED COB Down lights, LED moudle LED Panel lights and DIY products by customer etc. We could provide the most reliable light solution to client s' application. Our products are getting CE, RoHS, ETL DLC approval these days and all the light source chips are of brand in Epistar, Samsung, Edison, Nichia, Citizen, CREE and Luxeon etc.

Equipped with automatic SMT production lines testing room aging room dispensing room and all comprehensive processing technology in this industry. We got professional team who are in rich experience of processing technology engineering testing and other related fields. The production system is according to the standard of ISO9001: 20000. All the products will be sent to aging room for life testing and then must pass the strict tests of the Quality Control Dept. Before shipping. Our products are Environmentally-friendly Energy-saving High efficient and with long-lifespan. Our products have been successfully used in widely: Such as Famous hotels Big Chain stores, museum and various business centers and so on.

We are adhering to the principle of" Honesty Cooperation aspects and Win-Win" and we are doing our utmost to satisfy our clients 'personalization demand.

Certification

Cool White 3000*3300k IP40 LED Linear Light for Offices

FAQ

1. Q: Can I get some samples?
A: Yes,sample order is available for quality check and market test.
2. Q: What's the delivery time?
A: Usually below 100pcs is 3 days quick delivery.
3. Q: How long is the warranty period ?
A:  Non-artificial damage,  one years warranty
4. Q: Do you have the products in stock?
A: Yes ,of course
5. Q: Freight Cost?
A: The shipping cost depends on different weight;
We will choose the cheapest and safest way according your detail quantities.
6. Q: How does your factory do regarding the quality control?
A: Quality is priority. Every product will be fully assembled and carefully tested before packing and shipping.
